S1415 PRO Solid Carbide Compression Spiral Router Bit - 2 Flutes - 1/4 SD - 1/4 CD - 1 CL - 2-1/2 OL - 3/16 UCL

S1415 PRO Solid Carbide Compression Spiral Router Bit - 2 Flutes - 1/4 SD - 1/4 CD - 1 CL - 2-1/2 OL - 3/16 UCL

Regular price $23.97
Regular price Sale price $23.97
Sale Sold out
Tax included. Shipping calculated at checkout.
Rotation Compression Coating /
Shank Diameter 1/4" Router Bits Types 1/4" Shank Spiral Bit
Cutting Diameter 1/4" Product Series PRO-Series
Cutting Length 1" Cutting Edge Type Solid Carbide
Overall Length 2-1/2" Measurement Imperial
Flutes 2 Machinery Type Handheld Router, Router Table, CNC Router
Material Hardwoods, Softwoods, Laminate, Melamine, Plywood, MDF, Chipboard, Foamcore, Light Board, Aluminum Foamcore, Veneered Plywood, Particle, OSB, Solid Surface Material, Plastic, Acrylic
Rotation Compression
Shank Diameter 1/4"
Cutting Diameter 1/4"
Cutting Length 1"
Overall Length 2-1/2"
Flutes 2
Coating /

No Code Needed!
Buy 3 or More, Save 25% OFF
FREE SHIPPING IN USA

Product Description with Gradient Mask

Why Choose Spiral Router Bits Instead of Straight Bits?

  • Spiral router bits combine a shearing action with an augering action for chip clearance. This dual action not only produces a clean and accurate cut but also efficiently clears chips from the cut area, enhancing the overall cutting experience.

What is Compression (Up-Cut & Down-Cut) Bits

What is Compression (Up-Cut & Down-Cut) Bits

  • Features: Compression bits combine the features of both up-cut and down-cut bits. The top part of the bit is designed to be down-cut, improving the top edge finish, while the bottom part is up-cut, enhancing the finish on the bottom side of the material. This up-cut down-cut action is what leaves a sharp, clean edge on both edges of your workpiece.
  • Applications: The preferred bit for cutting laminated materials or any situation where both sides of the material are visible and require a fine finish.
  • Considerations: To fully benefit from a compression bit, it's crucial to make the initial cut deeper than the length of the up-cut flutes to prevent any tear-out or chipping on either side of the material.

Why Choose ZahyoX 1/4" Shank Spiral Router Bits?

  • Geometry Specs: - 1/4" Cutting Diameter, 1/4" Shank, 1" Cutting Length, 2-1/2" Overall Length, 2 Flutes, Compression (Up and Down Cut) Spiral.
  • Guaranteed Quality Control: - Made of industrial quality WC-Co solid carbide with patented technology, produced by 5-axis CNC grinding machine with German Bosch Rexroth CNC systems and servo motors, ensure consistency and high precision in each ZahyoX router bit.
  • Excellent for Cutting: Perfect for roughing, finishing, slotting, 3d contouring, plunging, surfacing and engraving on various solid kinds of wood, plywood, MDF, composites, acrylic, plastic, aluminum and soft metals.
  • Continuous Product Iteration: - The kickback-reducing design prevents overfeeding and tear-out. The geometry design has been iterated hundreds of times to ensure a perfect balance between tool life and cutting efficiency. We test our bits systematically on various machines and materials to ensure performance.
  • Reliable Brand and Team: - ZahyoX provides industrial-quality solid carbide material and router bits at an affordable price, by using superior materials, cutting-edge machinery, and patented technology. Making woodworking tools is our sole business for over two decades. We treat our products like art and fully guaranteed with an online customer support team.
OFFICIAL PARAMETERS FILES BY ZahyoX
View full details
Image SKU Type Rotation Flutes CD SD CL OL Stock Quantity Price Cart
S1415 Flat End Mill Compression 2 1/4" 1/4" 1" 2-1/2"
$23.97 USD
S1414 Flat End Mill Compression 2 1/4" 1/4" 1" 2-1/2"
$25.97 USD
S1401 Flat End Mill Upcut 2 1/4" 1/4" 1" 2-1/2"
$14.97 USD
S1418 Flat End Mill Compression 2 1/4" 1/4" 1" 2-1/2"
$20.37 USD
