S1404 Solid Carbide Compression Spiral Router Bit - 2Flutes - 1/4 SD - 1/4 CD - 1 CL - 2-1/2 OL

S1404 Solid Carbide Compression Spiral Router Bit - 2Flutes - 1/4 SD - 1/4 CD - 1 CL - 2-1/2 OL

Regular price $18.37
Regular price Sale price $18.37
Sale Sold out
Tax included. Shipping calculated at checkout.
  • Router Bits Types: Flat End Mill
  • Cutting Edge Type: Solid Carbide
  • Rotation: Compression
  • Cutting Diameter: 1/4"
  • Shank Diameter: 1/4"
  • Cutting Length: 1"
  • Overall Length: 2-1/2"
  • Flutes: 2
  • Coating: /
  • Measurement: Imperial
  • Machinery Type: Handheld Router, CNC Router, Router Table
  • Material: Hardwoods, Softwoods, Plywood, MDF, HDF, LDF, Laminates, Melamine, Particle, Chipboard, Light Board

No Code Needed!
Buy 3 or More, Save 25% OFF
FREE SHIPPING IN USA

Product Description with Gradient Mask


Why Choose Spiral Router Bits Instead of Straight Bits?

  • Spiral router bits combine a shearing action with an augering action for chip clearance. This dual action not only produces a clean and accurate cut but also efficiently clears chips from the cut area, enhancing the overall cutting experience.

What is Compression (Up-Cut & Down-Cut) Bits

What is Compression (Up-Cut & Down-Cut) Bits

  • Features: Compression bits combine the features of both up-cut and down-cut bits. The top part of the bit is designed to be down-cut, improving the top edge finish, while the bottom part is up-cut, enhancing the finish on the bottom side of the material. This up-cut down-cut action is what leaves a sharp, clean edge on both edges of your workpiece.
  • Applications: The preferred bit for cutting laminated materials or any situation where both sides of the material are visible and require a fine finish.
  • Considerations: To fully benefit from a compression bit, it's crucial to make the initial cut deeper than the length of the up-cut flutes to prevent any tear-out or chipping on either side of the material.

Why Choose ZahyoX 1/4 inch Shank Router Bits?

  • Geometry Specs: 1/4" Cutting Diameter, 1/4" Shank, 1" Cutting Length, 2-1/2" Overall Length, 2 Flutes, Compression (Up and Down Cut) Spiral.
  • Industrial-grade Solid Carbide: Made of industrial-quality Solid Carbide, reinforced with Tungsten Carbide cutters. This 1/4-inch compression router bit is specifically designed to provide a high-quality finish and efficient cuts.
  • Excellent for Cutting: Perfect for CNC sizing, cutting, copying and routing plywood, OAK, MDF, other hardwood materials, plastic, laminates and soft metals.
  • Maximize Efficiency: Kickback-reducing design prevents overfeeding and tear out. Advanced cutting geometry for superior chip evacuation and finish quality. Offering better cuts and efficiency than other bits on the market.
  • Trusted Brands: ZahyoX provides industrial quality CNC & woodworking tools at an affordable price, by using superior materials, cutting-edge machinery and patented technology. Fully guaranteed with online customer support team.
OFFICIAL PARAMETERS FILES BY ZahyoX
View full details
Image SKU Type Rotation Flutes CD SD CL OL Stock Quantity Price Cart
S1404 Flat End Mill Compression 2 1/4" 1/4" 1" 2-1/2"
$18.37 USD
S1413 Flat End Mill Compression 2 1/4" 1/4" 5/8" 2-1/2"
$25.97 USD
S1414 Flat End Mill Compression 2 1/4" 1/4" 1" 2-1/2"
$25.97 USD
S1415 Flat End Mill Compression 2 1/4" 1/4" 1" 2-1/2"
$23.97 USD
S1418 Flat End Mill Compression 2 1/4" 1/4" 1" 2-1/2"
$20.37 USD
