S1212 PRO-1/2" Shank Compression Solid Carbide Spiral Router Bit - 2 Flutes - 1/2" Cutting Dia - 1-1/4" Cutting Length - 3" Overall Length - 1/2" Upcut Length
S1212 PRO-1/2" Shank Compression Solid Carbide Spiral Router Bit - 2 Flutes - 1/2" Cutting Dia - 1-1/4" Cutting Length - 3" Overall Length - 1/2" Upcut Length
Regular price
$61.97
Regular price
Sale price
$61.97
Unit price
per
Shipping calculated at checkout.
| Rotation | Compression | Coating | / |
|---|---|---|---|
| Shank Diameter | 1/2" | Router Bits Types | 1/2 Shank Spiral Bit |
| Cutting Diameter | 1/2" | Product Series | PRO-Series |
| Cutting Length | 1-1/4" | Cutting Edge Type | Solid Carbide |
| Overall Length | 3" | Measurement | Imperial |
| Flutes | 2 | Machinery Type | CNC Router |
| Material | Hardwoods, Softwoods, Laminate, Melamine, Plywood, MDF, Chipboard, Foamcore, Light Board, Aluminum Foamcore, Veneered Plywood, Particle, OSB, Solid Surface Material, Plastic, Acrylic | ||
| Rotation | Compression |
|---|---|
| Shank Diameter | 1/2" |
| Cutting Diameter | 1/2" |
| Cutting Length | 1-1/4" |
| Overall Length | 3" |
| Flutes | 2 |
| Coating | / |
Order by 4:30 PM EST to Ship Today.
Couldn't load pickup availability
CNC Software Tool File Database
| Image | SKU | Rotation | Flutes | CD | SD | CL | OL | Stock | Quantity | Price | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
S1212 | Compression | 2 | 1/2" | 1/2" | 1-1/4" | 3" | ||||
|
S1211 | Compression | 2 | 1/2" | 1/2" | 1-1/4" | 3" | ||||
|
S1207 | Downcut | 3 | 1/2" | 1/2" | 1-1/2" | 3-1/2" | ||||
|
S1208 | Downcut | 3 | 1/2" | 1/2" | 1-1/2" | 3-1/2" | ||||
|
S1201 | Compression | 2 | 1/2" | 1/2" | 1-1/4" | 3" | ||||
|
S1202 | Compression | 2 | 1/2" | 1/2" | 1-1/4" | 3" | ||||
|
S1203 | Compression | 2 | 1/2" | 1/2" | 2" | 4" | ||||
|
S1204 | Compression | 2 | 1/2" | 1/2" | 2" | 4" | ||||
|
S1205 | Upcut | 2 | 1/2" | 1/2" | 1-1/4" | 3" | ||||
|
S1206 | Upcut | 2 | 1/2" | 1/2" | 1-1/4" | 3" | ||||
|
S1209 | Compression | 2 | 1/2" | 1/2" | 1" | 3" |
Why Choose Spiral Router Bits Instead of Straight Bits?
- Spiral router bits combine a shearing action with an augering action for chip clearance. This dual action not only produces a clean and accurate cut but also efficiently clears chips from the cut area, enhancing the overall cutting experience.
What is Compression (Up-Cut & Down-Cut) Bits?
- Features: Compression bits combine the features of both up-cut and down-cut bits. The top part of the bit is designed to be down-cut, improving the top edge finish, while the bottom part is up-cut, enhancing the finish on the bottom side of the material. This up-cut down-cut action is what leaves a sharp, clean edge on both edges of your workpiece.
- Applications: The preferred bit for cutting laminated materials or any situation where both sides of the material are visible and require a fine finish.
- Considerations: To fully benefit from a compression bit, it's crucial to make the initial cut deeper than the length of the up-cut flutes to prevent any tear-out or chipping on either side of the material.
Why Choose ZahyoX 1/2" Shank Spiral Router Bits?
- Geometry Specs: - 1/2" Cutting Diameter, 1/4" Shank, 1-1/4" Cutting Length, 3" Overall Length, 2 Flutes, Compression (Up and Down Cut) Spiral.
- Guaranteed Quality Control: - Made of industrial quality WC-Co solid carbide with patented technology, produced by 5-axis CNC grinding machine with German Bosch Rexroth CNC systems and servo motors, ensure consistency and high precision in each of ZahyoX router bit.
- Continuous Product Iteration: - The kickback-reducing design prevents overfeed and tear out. The geometry design has been iterated hundreds of times to ensure a perfect balance between tool life and cutting efficiency. We test our bits systematically on various machines and materials to ensure the performance.
- Excellent for Cutting: Perfect for roughing, finishing, slotting, 3d contouring, plunging, surfacing and engraving on various solid woods, plywood, MDF, composites, acrylic, plastic, aluminum and soft metals.
- Reliable Brand and Team: - ZahyoX provides industrial quality solid carbide material and router bits at an affordable price, by using superior materials, cutting-edge machinery and patented technology. Making woodworking tools is our sole business for over two decades. We treat our products like art and fully guaranteed with online customer support team.
