How to Flatten a Wood Slab with a Slab Flattening Router Bit

Whether you're making a charcuterie board or a cutting board, using a slab flattening bit is the most efficient ways to get wood blocks into flat surfaces. In this article, we’ll explain the process of flattening a slab and help you choose between a 1/2" shank or 1/4" shank spoilboard flattening bit. As well as recommend the ideal feeds and speeds for each.

What is a Slab Flattening Router Bit?

A slab flattening router bit or sometimes called a fly cutter, is designed to remove high points and uneven areas from a wood slab, leaving a smooth and leveled surface. These bits have a wide, flat cutting area with 2-4 blades, allowing them to efficiently plane large surfaces like spoilboards, wood slabs, and even countertops. The process is typically done using a router sled or CNC, which should hold the router steady as you pass it over the slab.

Step-by-Step Guide to Flattening a Slab

1. Prepare Your Workspace

Before starting, ensure the slab is securely clamped to a flat workbench or surface. Stability is essential to getting an even cut, so make sure your slab stays steady during the flattening process.

2. Build or Use a Router Sled

Router Sled Created by Walker's Woodworks (https://www.walkersww.com/blog/newrails)

If you don't own a CNC, a router sled would be essential for controlling the router’s movement. You can either purchase a pre-made sled or build your own using plywood and guide rails. The sled allows the router to glide smoothly over the entire surface of the slab, guaranteeing a flat finish.

3. Select the Right Flattening Bit

Choosing the correct spoilboard surfacing bit is crucial for an efficient flattening process. A wide, flat-bottomed bit ensures fast and even material removal. However, there are countless options on the market. Most woodworkers prefer bits with replaceable carbide blades for their longevity and cost-effectiveness.

4. Adjust the Router Depth

Set the flattening bit depth just below the slab's highest point, around 1/16" to 1/8" depending on the bit you're using. Always start with shallow cuts—removing too much material at once can lead to gouges or rough cuts. Adjust the depth for successive passes as needed.

1/4

5. Flatten the Slab

With the router sled in place and your slab flattening bit installed, start making slow, steady passes across the slab. Overlap each pass slightly to ensure no sections are missed. Paint chalk across the surface to ensure every part of the slab is passed over.

6. Check for Flatness

After the first pass, check the slab’s surface with a straight edge or level. Adjust the flattening bit’s depth and continue with additional passes if necessary until the entire surface is flat.

7. Finish the Surface

Once the slab is flat, sand the surface to remove any tool marks and prepare it for finishing or other steps

Choosing Between a 1/2" Shank and 1/4" Shank Flattening Bit

ZahyoX Slab Flattening Bit Colleciton

1/2" Shank Spoilboard Surfacing Bit

  • Stability & Reduced Vibration: Provides better stability and reduces vibration during large-scale slab flattening projects.
  • Greater Durability: More robust and able to withstand heavy-duty tasks.
  • Better Heat Dissipation: Allows for better heat dissipation during long sessions.
  • Ideal for Larger Routers: Best for full-size routers and CNC machines.

1/4" Shank Spoilboard Surfacing Bit

  • Compact Routers: Ideal for smaller or trim routers that can’t accept 1/2" shank bits.
  • Lighter Duty Tasks: Suitable for smaller slabs or lighter surfacing projects.
  • More Affordable: Budget-friendly for occasional or hobbyist use.

1/2" Shank Spoilboard Surfacing Bit

  • RPM: 10,000 to 12,000
  • Feed Rate: 120 to 150 (IPM)
  • Depth of Cut: 1/16" to 1/4" per pass

1/4" Shank Spoilboard Surfacing Bit

  • RPM: 9,000 to 14,000
  • Feed Rate: 100 to 150 IPM
  • Depth of Cut: 1/16" to 1/8" per pass
1/4

Conclusion

Flattening a wood slab with a router is a straightforward process when equipped with the right tools. Using a slab flattening router bit and selecting the correct spoilboard surfacing bit ensures fast and precise material removal. Investing in the right bit will make slab flattening much easier and more efficient.
